Intel® Core 8th I3/I5/I7 processor.
21.5" industrial-grade display, 10-point capacitive touch screen.
Standard 8GB DDR4 memory, maximum support 16GB.
6*USB, 2*COM, 1*HD, 1*VGA.
1* RJ45 Gigabit network interface.
The protection level of the front panel can reach IP65.
With front binocular recognition camera.
5G full Netcom, dual-band WIFI.
System Hardware | |
CPU | Intel® Core™ 8th I3/I5/I7 processor |
Watchdog | Support hardware reset function (256 levels, 0~255 seconds) |
Memory | 8GB DDR4 RAM, up to 16GB |
Storage | MSATA: 64GB, up to 512GB |
Display | |
LCD Type | 21.5″ LCD |
Touchscreen Type | capacitive touch screen |
Max. Resolution | 1920*1080 |
Luminance | 250 cd/m2 |
Contrast Ratio | 1000: 1 |
OS | |
OS | Windows7/8.1/10, Linux, Ubuntu |
I/O Ports | |
USB | 4*USB3.0, 2*USB2.0 |
Serial port | 2*RS232 (optional 1~2*RS485) |
LAN | 1* RJ45 Gigabit network interface |
Audio | 1*Line-out+1*Mic-in |
Video | 1*HD, 1*VGA |
GPIO | 1*GPIO(4 channels) (optional) |
Expand | 1*Mini PCIe(dual-band Wifi, with 1 external antenna) |
Camera | Support 200W front infrared binocular recognition camera |
SIM Card | * External SIM card holder (support 5G full Netcom, with 4 external antennas) |
Power | |
Power Supply | Optional 9~36V wide voltage input, standard 12V/5A power adapter |
